FS5 – Fire Barrier Curtains

Fire curtains help to establish thermal insulation inside the cab of the vehicle and/or heavy machinery in extreme and unexpected situations of exposure to fire as a consequence of entrapment inside the vehicle.

FIRE BARRIER CURTAINS

It provides protection against radiation and convection; in order to achieve the appropriate level of protection it is essential that personnel are properly secured with the specific personal protective equipment for firefighting, in addition to having self-contained breathing apparatus, external protection system in the form of sprinklers and/or FS1 self-protection nozzle.

Connections sewn with thread and Kevlar tape.
4-layer flame retardant fabric.

Main uses:

  • Light and heavy wildland vehicles.
  • Heavy machinery.

Technical characteristics

Conformities: European General Product Safety Directives 2001/95/CE, Royal Decree 1801/2003 and Directives on minimum health and safety requirements for the use of work equipment by workers, Directive 89/655/CEE, Directive 95/63/CEE, Directive 2001/45/CE and Royal Decree 1215/1997.

Certification of the fabric: The set of layers that make up the fabric has been certified by a notified body accredited by ENAC and in accordance with the UNE EN ISO 11612 and EN 469/A1 standards, according to:

  • EN ISO 15025
  • ISO 9151
  • EN ISO 6942
  • ISO 12127-1
  • ISO 17493
  • EN ISO 13934-1
  • EN ISO 13937-2
  • EN ISO 13935-2

Accredited Notified Body Number: 0161
Test report number: 2017 EP3190

Models and description

Set of fireproof aluminized curtains for SINGLE CABIN consisting of 3 units to cover 3 windows (2 side and 1 front).

Set of fireproof aluminized curtains for DOUBLE CABIN consisting of 5 units to cover 5 windows (4 lateral and 1 front).

Set of fireproof aluminized curtains for SINGLE CABIN consisting of 4 units to cover 4 windows (2 lateral, 1 front and 1 rear).

Set of fireproof aluminized curtains for DOUBLE CABIN consisting of. 6 units to cover 6 windows (4 side, 1 front and 1 rear).

Dimensions and weights

According to vehicle type and cab.

Materials

  • 1st and 2nd outer layer: with special protection against radiant heat, 3rd and 4th inner layer: with special thermal protection.

Performance

Indoor radiant and convective heat protection against flames with a maximum power of up to 600 kW, a medium flame speed of up to 20 km/h and a minimum distance of 1.5 m from the front of the shelter.

Protection against radiant and convective heat inside, against flames up to 10.5 m wide with a maximum power of up to 80 MW, without forced ventilation and at a minimum distance of 2 m from the front of the shelter.

Performance level obtained in EN ISO 11612 fabric certification

  • A1 (EN ISO 15025, Procedure A)
  • A2 (EN ISO 15025, Procedure B)
  • B2 (ISO 9151)
  • C4 (EN ISO 6942, Method B)
  • F3 (ISO 12127-1)
  • COMPLIES (ISO 17493)
  • COMPLIES (EN ISO 13934-1)
  • COMPLIES (EN ISO 13937-2)
  • COMPLIES (EN ISO 13935-2)

Performance level obtained in the EN 469/A1 fabric certification:

  • LEVEL 2 (ISO 9151)
  • LEVEL 2 (EN ISO 6942, Method B)
  • COMPLIES (ISO 17493)
  • COMPLIES (EN ISO 13934-1)
  • COMPLIES (EN ISO 13937-2)
  • COMPLIES (EN ISO 13935-2)

Anchoring system

  • by carabiner or similar to fixed points on the truck.

ISK Fire Survival

Fire Intervention in Forest

Despite being an indispensable element in the comprehensive safety kit, to deal with risk situations due to entrapment with pumper vehicles, its different of features combined with its effectiveness, make the device an element with a variety of applications in the different firefighting and rescue services.
It is used in interventions related to the protection of people or property, that may be threatened by fire, as well as an element of special interest to help establish and promote the protection, extinction and safety of personnel involved in all those operations of extinction and rescue that imply an imminent risk or threat to combatant personnel. This, combined with its adaptation ability to the different sources of water supply (fixed-mobile), coming from boost systems and firefighting networks, such as extinguishing vehicles, motor pumps, etc; make it a device with applications in different sectors and users.
